Rotating Beacon HELLA 2RL 007 337-011 OE Ref KDWHLO9654
Key Specification:
- Diffusing Lens Material: PC (Polycarbonate)
- EAN: 4082300045307
- Fulfils ECE norm: R10
- Fulfils ECE norm: R65
- fulfils test standard: RCM
Sale
£ 126
£ 105 excl. VAT
In Stock
- Free ShippingFor orders over £75
- Top-Notch SupportMonday To Friday
- 100% SafetyOnly secure payments
- Hot OffersDiscounts up to 70%
Diffusing Lens Material
PC (Polycarbonate)
EAN
4082300045307
Fulfils ECE norm
R10
Fulfils ECE norm
R65
fulfils test standard
RCM
Height [mm]
174
HELLA
Rotating Beacon
Housing Colour
Black
Housing material
EPDM (ethylene propylene diene Monomer (M-class) rubber)
Lamp Type
H1
Length [cm]
18.5
Lens Colour
yellow (amber)
Light colour
Amber
Light Design
Halogen
Light Function
With rotating warning signal
Mounting Type
Bolted
Mounting Type
Mounting
OEM Reference number
183450618
Operating temperature from [C]
-40
Operating temperature to [C]
+60
Other Info
Rotafix
Outer Diameter 1 [mm]
135
Packing Unit
1
Plug Type
Blade Terminal
Power Consumption [W]
70
Protection Type (IP Code)
IP5K4K
Protection Type (IP Code)
IPX9K
Quantity
1
Rotating beacon RPM [1/min]
174
Supplementary Info
with bulb
Supplementary Info
Electromagnetic Compatibility (EMC)
Supplementary Info
1732-24V - KL Rotafix F - ROTAFIX F
Voltage [V]
24
Weight [kg]
0.69
Need a Rotating Beacon OE Ref KDWHLO9654 for Your various?
This one's manufactured by HELLA and built to OEM reference 183450618, so it replaces the original part without any compromise on fit or function.
Reference 2RL 007 337-011, EAN: 4082300045307 is printed on the part itself, so you can double-check it against what you're removing.
- with bulb
- Electromagnetic Compatibility (EMC)1732-24V - KL Rotafix F - ROTAFIX F
Fitment on various models can vary by year, so it's worth confirming with the OEM reference or our vehicle lookup tool rather than ordering on name alone.
If it turns out not to be the one, the rest of Lighting is sorted by vehicle so you can find the right match faster.
Reference number(s) comparable with the original spare part number
OE reference number(s) comparable with the original spare part number
