Pressure Switch NISSENS 301020 OE Ref 7788280
Key Specification:
- Closing pressure (21) [bar]: 24-5
- Closing pressure (22) [bar]: 11
- Closing pressure (23) [bar]: 28
- Connector Shape: rectangular
- EAN: 5707286538368
Sale
£ 36
£ 30 excl. VAT
Out of stock
- Free ShippingFor orders over £75
- Top-Notch SupportMonday To Friday
- 100% SafetyOnly secure payments
- Hot OffersDiscounts up to 70%
Closing pressure (21) [bar]
24-5
Closing pressure (22) [bar]
11
Closing pressure (23) [bar]
28
Connector Shape
rectangular
EAN
5707286538368
First Fit
Yes
NISSENS
Pressure Switch
Notes
FIRST FIT
Number of pins
4
OEM Reference number
60815596
Opening pressure (21) [bar]
3-5
Opening pressure (22) [bar]
15-2
Opening pressure (23) [bar]
21
Refrigerant
R 134a
Spanner Size
HEX 19
Supplementary Info
6ZL351028151
Thread Size
7/16-20 UNF
Version
SWITCH
Version
Female
Voltage [V]
12
Find the Right Pressure Switch OE Ref 7788280 for Your ALFA ROMEO, FIAT, LANCIA
Fitting a ALFA ROMEO, FIAT, LANCIA that needs a new Pressure Switch OE Ref 7788280? This one is built by NISSENS to OEM reference 60815596, so it slots in as a straight swap for the original part — no modifications, no guesswork.
It's listed under NISSENS part number 301020, EAN: 5707286538368, which you can cross-check against your old part before ordering to be sure it's the right fit.
- 6ZL351028151
Before You Order
Double-check fitment against OEM reference 60815596, or run your registration through our vehicle lookup tool — some ALFA ROMEO, FIAT, LANCIA models share a platform across several years, so it's worth confirming rather than assuming.
Not quite the right one? The full Air Conditioning range has other options worth a look.
Reference number(s) comparable with the original spare part number
OE reference number(s) comparable with the original spare part number
