Brake Drum ATE 24.0220-3035.1 OE Ref 55703042
Key Specification:
- Bolt Hole Circle [mm]: 100.0
- Bore Diameter [mm]: 14.0
- EAN: 4006633309554
- Inner brake drum diameter [mm]: 203.0
- Inner Brake Drum Height [mm]: 45.0
Sale
£ 102
£ 85 excl. VAT
In Stock
- Free ShippingFor orders over £75
- Top-Notch SupportMonday To Friday
- 100% SafetyOnly secure payments
- Hot OffersDiscounts up to 70%
Bolt Hole Circle [mm]
100.0
Bore Diameter [mm]
14.0
EAN
4006633309554
Inner brake drum diameter [mm]
203.0
Inner Brake Drum Height [mm]
45.0
max. brake drum reboring dimension [mm]
204.7
Number of Holes
4
OEM Reference number
55701379
Outer brake drum diameter [mm]
249.5
Supplementary Info
Brake drum
Supplementary Info
480300
Support plate diameter [mm]
60.0
Test Mark
E1 90R-02D0324/1876
Total brake drum height [mm]
61.0
Need a Brake Drum ATE OE Ref 55703042 for Your FIAT, VAUXHALL, VAUXHALL/OPEL?
This one's manufactured by ATE and built to OEM reference 55701379, so it replaces the original part without any compromise on fit or function.
Reference 24.0220-3035.1, EAN: 4006633309554 is printed on the part itself, so you can double-check it against what you're removing.
- Brake drum480300
Fitment on FIAT, VAUXHALL, VAUXHALL/OPEL models can vary by year, so it's worth confirming with the OEM reference or our vehicle lookup tool rather than ordering on name alone.
If it turns out not to be the one, the rest of Braking System is sorted by vehicle so you can find the right match faster.
Reference number(s) comparable with the original spare part number
OE reference number(s) comparable with the original spare part number
